Precise Removal Pearl Color Sorter , 3-3.5 T/H Shrimp Sorting Equipment

    Buy cheap Precise Removal Pearl Color Sorter , 3-3.5 T/H Shrimp Sorting Equipment from wholesalers

    Buy cheap Precise Removal Pearl Color Sorter , 3-3.5 T/H Shrimp Sorting Equipment from wholesalers
    • Buy cheap Precise Removal Pearl Color Sorter , 3-3.5 T/H Shrimp Sorting Equipment from wholesalers

    Precise Removal Pearl Color Sorter , 3-3.5 T/H Shrimp Sorting Equipment

    Ask Lasest Price
    Brand Name : Coreprogram
    Model Number : BDX1600-2
    Price : Negotiable
    Supply Ability : 1000 sets per year
    Delivery Time : 15 working days
    Payment Terms : L/C, T/T
    • Product Details
    • Company Profile

    Precise Removal Pearl Color Sorter , 3-3.5 T/H Shrimp Sorting Equipment

    High Accuracy Precise Removal Reliable Quality Pearl Sorting Machine

    Product Superiority :
    1. High Speed Data Processing
    The fifth-generation FPGA chip has greatly improved the calculation speed and the amount of
    calculation data, and can easily realize the ultra-high-speed real-time calculation of massive
    data.
    2. Anti-fragmentation
    High-frequency solenoid valve, equipped with targeted positioning, flexible rejection, soft
    touch and other modules to protect all materials.
    3. Efficient Double Selection
    We provide slow and fast series, infrared series, anti-tracking deviation, four-view series single
    and double layer color sorters to meet the demands of customers at different purpose.

    Technical Parameters:

    ModelLayers NumberVoltage
    (V/Hz)
    Power
    (Kw)
    Sorting Accuracy(%)Capacity
    (t/h)
    Carryover
    Ratio
    Dimension(mm)
    (L*W*H)
    Weight
    (Kg)
    BDX640-11220/502.9>99.9%0.6-1.1>10:13380x2560x17201100
    BDX640-22220/503.4>99.9%1.0-1.5>10:13830x2560x25302100
    BDX1280-11220/504.7>99.9%1.5-2.0>10:13380x3050x17201312
    BDX1280-22220/508.2>99.9%2.5-3.5>10:13830x3050x25302560
    BDX1600-22220/508.75>99.9%3-3.5>10:15300x3750x32002765
    BDX1920-11220/505.85>99.9%2-2.5>10:13380x3840x17201920
    BDX1920-22220/509.5>99.9%3.5-4.0>10:13830x3840x25303765

    Note: The above parameters take dried shrimps with 10% impurities ratio as an example .
    Due to different raw materials and different impurities ratio , parameters above will vary
    ​ to some extent ,which are references for you choosing a suitable model.

    Sorting Case :

    Example of Flower Shrimp Sorting

    Raw Material Accepted Rejected

    Raw Material Accepted Yellow Accepted White

    FAQ:
    1. How about after-sale services overseas?
    After-sale services are available to overseas customers for training and installation.
    Internet + mobile app, making the operation and maintenance more convenient and easy.
    2. How to use the machine?
    We will provide the customers with the installation drawing and let our engineer to assist with
    you if needed.
    3. How could I believe that the machine will be workable for my materials?
    Sample sent for testing is welcomed. Or you send us three photos,the raw material, the good
    material (which is you want to accept) ,bad material (which is you want to reject). we send the
    sorting video to you or make video call with you.
    4. What is the warranty period?
    We provide a one-year whole-machine warantty. And we supply the spare parts at our
    purchasing price.
    5. Will you accept L/C as payment?
    Both L/C and T/T are OK.
    6. Do you have any other spare parts for us?
    Yes,we will supply you some basic spare parts .
    7. Which machine will work together with our sorting machine that you can supply ?
    Air compressor, Air tank, Air filters, Air dryer, light sources, cleaning brushes, etc.

    8. What's the capacity ?
    The capacity in the table is a little different due to different impurities ratio .
    We generally
    provide an output range.
