12 Chute Peanut Color Sorter / Cashew Colour Sorting Machine 1 year Warranty

    Buy cheap 12 Chute Peanut Color Sorter / Cashew Colour Sorting Machine 1 year Warranty from wholesalers

    Buy cheap 12 Chute Peanut Color Sorter / Cashew Colour Sorting Machine 1 year Warranty from wholesalers
    • Buy cheap 12 Chute Peanut Color Sorter / Cashew Colour Sorting Machine 1 year Warranty from wholesalers

    12 Chute Peanut Color Sorter / Cashew Colour Sorting Machine 1 year Warranty

    Ask Lasest Price
    Brand Name : Coreprogram
    Model Number : CVG-12
    Price : Negotiable
    Supply Ability : 1000 sets per year
    Delivery Time : 15 working days
    Payment Terms : L/C, T/T
    • Product Details
    • Company Profile

    12 Chute Peanut Color Sorter / Cashew Colour Sorting Machine 1 year Warranty

    12 Chute High Capacity Flexible Removal Peanut Cashew Nut Sorting Machine
    Product Superiority :
    1. Brand new photoelectric design LED light source, More energy-saving, low heat.
    2. The light source and the sorting box are set independently to reduce the interference of dust
    on the material sorting .
    3. Unique bottom exhaust dust removal system, excellent dust removal effect, stable performance
    in dusty environment .
    4. Easy to learn and operate .
    5. Simple optical system design, precise automatic calibration system , well-designed man-machine
    interface .

    Technical Parameters:

    ModelCapacity
    (t/h)
    Optimized Carryover
    (bad:good)
    Sorting Accuracy
    (%)
    Power
    (Kw)
    Voltage
    (V/Hz)

    Dimension

    L×W×H(mm)

    Weight

    (kg)

    XCS800.8-1.2>20:1>99.90.5-0.8220/50967*1553*1784286
    CVG-53-5>20:1>99.93.3220/502617*2077*17951532
    CVG-63.5-6>20:1>99.94.2220/502955*2077*17951752
    CVG-73.5-8>20:1>99.95.0220/503293*2077*17951910
    CVG-84-9>20:1>99.96.0220/503641*2077*17952170
    CVG-105-12>20:1>99.97.05220/504317*2077*17952520
    CVG-126-13>20:1>99.98.3220/504993*2077*17952960

    Note: Due to different raw materials and different impurities ratio , parameters above will
    vary to some extent ,which are references for you choosing a suitable model.

    Working Schematic :

    From the schematic ,we can learn that when the materials enter the chute ,the sensor will recognize the shape and color of materials, if there are some specked ,splitted ,rotten and other defects,the ejector system will release compressed air to change the path of rejected materials with defects into rejected hole . The accepted materials will come out from the accepted hole .

    Sorting Case :
    Example of Macadamia and Peanuts Sorting
    Accepted Rejected Accepted Rejected

    Our Service:

    • One year quality warranty for the machine and spare parts.
    • Engineers service for installation overseas.
    • Whole-life after-sales service and free consultation.
    • Customized requirements available.
    • Technician guide at the site.
    • 24 Hrs online service.
