Intelligent Interconnection Dehydrated Onions Color Sorter Machine
Main Features :
1. Brand new photoelectric design LED light source, More
energy-saving, low heat.
2. The light source and the sorting box are set independently to
reduce the interference
of dust on the material sorting .
3. Unique bottom exhaust dust removal system, excellent dust
removal effect, stable
performance in dusty environment .
4. Easy to learn and operate .
5. Simple optical system design, precise automatic calibration
system , well-designed
man-machine interface .
6. Coreprogram Color Sorting machine provides customized designed
color sorter
machine according to the demands of the end-users.
7. Logo , color , size can be customized.
Technical Parameters:
| Model | Layers Number | Voltage
(V/Hz) | Power
(Kw) | Sorting Accuracy(%) | Capacity
(t/h) | Carryover
Ratio | Dimension(mm)
(L*W*H) | Weight
(Kg) |
| BDX640-1 | 1 | 220/50 | 2.9 | >99.9% | 0.3-0.7 | >10:1 | 3380x2560x1720 | 1100 |
| BDX640-2 | 2 | 220/50 | 3.4 | >99.9% | 0.4-1.0 | >10:1 | 3830x2560x2530 | 2100 |
| BDX1280-1 | 1 | 220/50 | 4.7 | >99.9% | 0.6-1.0 | >10:1 | 3380x3050x1720 | 1312 |
| BDX1280-2 | 2 | 220/50 | 8.2 | >99.9% | 1.0-1.5 | >10:1 | 3830x3050x2530 | 2560 |
| BDX1600-2 | 2 | 220/50 | 8.75 | >99.9% | 1.5-2.0 | >10:1 | 5300x3750x3200 | 2765 |
| BDX1920-1 | 1 | 220/50 | 5.85 | >99.9% | 1.3-1.8 | >10:1 | 3380x3840x1720 | 1920 |
| BDX1920-2 | 2 | 220/50 | 9.5 | >99.9% | 2.0-2.5 | >10:1 | 3830x3840x2530 | 3765 |
Note: The above parameters take dehydrated carrots with 5%
impurities ratio as an example .
Due to different raw materials and different impurities ratio ,
parameters above will vary
to some extent ,which are references for you choosing a suitable
model.
Working Schematic :
From the schematic ,we can learn that when the materials enter the
chute (4),the front CCD camera(5) and the rear CCD camera(8) will
recognize the shape and color of materials, if there are some
specked ,splitted ,rotten and other defects,the ejector system(9)
will release high-pressure air to change the path of rejected
materials with defects into rejected hole (10).The accepted
materials will come out from the accepted hole (11).
Sorting Case:
Example Of Dehydrated Onions Sorting
Raw Materials Accepted Onions Rejected Onions
